상세사양
|
|
IR 해상도 (FPA size) |
160 x 120 FPA Uncooled Microbolometer |
|
적외선 대역 |
7.5 μm to 14 μm (long wave) |
|
이미지캡쳐 주파수 |
9 Hz or 30Hz versions |
|
NETD (열감도) |
≤ 0.10 °C at 30 °C target temp (100 mK)
0.10 °C at 30 °C target temp (100 mK) |
|
FOV (화각) |
22.5 °H x 31 °V |
|
IFOV (공간분해능) |
3.39 mRad |
|
온도측정범위
(not calibrated below -10 °C) |
-20 °C to +250 °C |
|
정확도 |
± 2 °C or 2 % (at 25 °C nominal, whichever is greater) |
|
초점방식 |
Focus-free 1.2 m (4 ft) and beyond |
|
IR-Fusion® technology |
YES, PIP, full IR, full Visible (Ti105)
No, full IR only (Ti100) |
|
칼라알람 |
- |
|
기본팔레트 |
Blue-Red, Grayscale, Ironbow, Amber |
|
Ultra Contrast™ palettes
|
