| DC Voltage |
|
0.1-0.25-2.5-10-50-250-1000V(20㏀/V) ±4%F.S |
|
| DCV NULL |
|
±5V. 25V ±4%F.S |
|
| DC Current |
|
0-50㎂-2.5㎃-25㎃-250㎃-10A ±4%F.S |
|
| AC Voltage |
|
0-10-50-250-1000V(9㏀/V) ±5%F.S |
|
| Resistance |
|
0-2㏀-20㏀-200㏀-2㏁-20㏁ ±4%F.S |
|
| Decibels |
|
-10㏈∼+22㏈(AC10V)∼+62㏈ |
|
| LI |
|
0-150㎂-1.5㎃-15㎃-150㎃ |
|
| LV |
|
0-3V |
|
| hFE |
|
0-1000 |
|
| Battery check |
|
1.5V (load250㎃) |
|
| Continuity |
|
Beeper(50Ω or less), LED(at below 10Ω) |
|
| Power source |
|
R6(1.5V)×2, 6F22(9V)×1 |
|
| Size & Weight |
|
150×100×38㎜, Approx, 300g(NET) |
|
| Accessories |
|
Test leads, Carrying case |
