| SPECIFICATIONS |
|---|
| Measuring function |
: |
AC load current |
|---|
| Measuring method |
: |
Dual slope integration mode |
|---|
| AC conversion |
: |
Average sensing rms reading |
|---|
| Display |
: |
3.5 digit LCD max. reading of 1999 with annunciators |
|---|
| Measuring range |
: |
AC 0～20A/600A (50Hz/60Hz), 2 ranges manual |
|---|
| Structure |
: |
Splash proof |
|---|
| Jaw opening capability |
: |
φ35mm |
|---|
| Accuracy |
: |
(23℃±5℃ 80%RH or less)
|
Range |
Resolution |
Accuracy(50/60Hz) |
|---|
|
AC 20A |
0.01A |
±2%rdg±8dgt | |
AC 600A |
1A |
0～400A : ±2%rdg±8dgt
400A～600A : ±3%rdg±8dgt |
|
|---|
| Peak hold function |
: |
LED lamp |
|---|
| Sampling time |
: |
2 times/sec |
|---|
| Low battery indication |
: |
"B" mark on LCD |
|---|
| Insulation resistance |
: |
100MΩ or more by DC 1000V insulation tester
(Between hot stick connector and core of CT) |
|---|
| Withstanding voltage |
: |
AC 15kV, 1 minute
(Between hot stick connector and core of CT) |
|---|
| Limitation of circuit voltage |
: |
AC 80Vrms to 7000Vrms |
|---|
| Operating temperature |
: |
0～40℃, less than 80%RH (without condensation) |
|---|
| Power supply |
: |
AAA size battery×2 |
|---|
| Size and weight |
: |
70(W)×290(H)×32(D)mm, Approx. 350gs. |
|---|
| Accessories |
: |
| Carrying case |
: |
1 | | Instruction manual |
: |
1 | | Batteries |
: |
2 |
|
|---|
| Option |
: |
Hot stick |
|---|
